Highlights

BEST IN CLASS FOR

  • WOOD BASED PANELS:
    PB/SPB
    OSB/LSB/FOSB
    MDF/HDF
    PLYWOOD
    LVL

MAIN FEATURES

  • Sturdy mechanical assembly of the structure and of the sensors in particular
  • A correct measurement is made without contact with the board
  • Diagnostics and control of the system’s operating status
  • Fast measuring speed
  • An efficient pneumatic system ensures that the transmitters are kept clean, reducing maintenance
  • Incorporated database to store the measurement reports, for statistical analysis and graph printouts
  • Numerous graphs available such as: blister position on board, production trend blisters, opening trend, board quality trends
  • Network linking possible with TCP/IP protocol, for Siemens S7 and Allen-Bradley ControlLogix

ADVANTAGES

  • Repeatability, reliability, comprehensive and accurate measurement
  • Improved production quality
  • On-line visualization of the production process
  • Quick and easy to install
  • Little maintenance required
  • It can be mounted on the same beam used to support the IMAL thickness gauge
