Highlights

BEST IN CLASS FOR

  • WOOD BASED PANELS:
    MDF/HDF
    PB/SPB
    OSB/LSB/FOSB
    INSULATION BOARDS
  • PRESSED WOOD PACKAGING:
    PALLET BLOCKS
  • PELLETS & ENERGY:
    WOOD PELLETS AND BLACK PELLETS

TECHNICAL FEATURES

  • Very strong double-roller chain feeder
  • Horizontal loading section connected with inclined lifting section
  • Moving bed equipped with transverse metal plates, overlapped and sealed by profiled shape
  • Front shaft fitted with direct transmission
  • Rear shaft fitted with chain tensioning devices
  • Self cleaning system with: closed bottom – rear reclaim screw conveyors – suction system or reclaim vertical screw conveyor
  • Automatic lubrication device for chains
  • Containment walls

BENEFITS

  • Easy loading of fractioned material, wet or dry, such as fresh or recycled chips, sawdust, shavings, etc.
  • Very efficient feeding of screens, cleaners, refiners, etc.
  • Except for front loader, operators are required from time to time only
  • Working speed freely adjustable by using frequency converter
  • Automatic cleaning and lubrication
  • High performance
