Highlights

BEST IN CLASS FOR

  • WOOD BASED PANELS:
    PB/SPB
    OSB/LSB/FOSB
    MDF/HDF

MAIN FEATURES

The SDS spark detection system conforms to the requirements of ATEX directive 2014/34/UE for use as intended in potentially explosive atmospheres due to the presence of combustible dust (zones 20, 21 or 22) with EU-type Examination Certificate.

  • Compliance with European Standards EN 60079-0; EN 60079-31
  • Extremely rapid system response
  • Emergency back-up power unit
  • Modular and expandable system
  • Incorporated database to store alarms and record operations carried out on the system
  • Infrared detectors with special fibre optics to withstand temperatures of up to 290 °C
  • No calibration
  • Auto-testing function to test sensor efficiency
  • Possibility of linking up with any kind of PLC
  • Constant electric control carried out on the extinguishing unit
  • Global monitoring of all plant areas as well as instant individual monitoring of any one area via the graphic displays provided (PC/display panel)
  • System can run independently and efficiently without PC
  • Easy access to any area of the plant
